PROSKİT MT-1232 DİGİTAL ÖLÇÜ ALETİ

DC Gerilim

400mV/4V/40V/400V ±(0.5%+4d)

600V ±(1.0%+4d)

AC Gerilim

4V/40V/400V ±(0.8%+6d)

600V ±(1.0%+6d)

DC Akım

400μA/4000μA ±(1.0%+10d)

40mA/400mA ±(1.0%+10d)

10A±(1.2%+10d)

AC Akım

400μA/4000μA ±(1.5%+10d)

40mA/400mA ±(1.5%+10d)

10A±(2.5%+15d)

Direnç

400Ω ±(0.8%+5d)

4k/40k/400K ±(0.8%+4d)

4MΩ ±(0.8%+4d)

40MΩ ±(1.2%+10d)

Frekans

1/10/100Hz ±(0.5%+10d)

1K/10K/100KHz ±(0.5%+10d)

1/10MHz ±(0.5%+10d)

Kapasitans

4nF ±(0.5%+90d)

40nF/400nF/4μF/40μF ±(3.5%+8d)

100μF ±(5.0%+8d)

Sıcaklık

(-20C~1000C) < 400C±(1.0+5d)

(-20C~1000C) >= 400C±(1.5+15d)

Çevrim

0.1%~99.9%

Süreklilik

Evet

Diod test

Evet

Sigorta

10A/250V

Güç Kaynağı

1

.

5V AA x 2 (dahil değildir)

Ebat

1

47 x 78 x 41 mm
